The Dingbo Three-ring Micro Powder Mill (ultrafine mill) is for super-fine grinding materials with hardness less than 6 in Moh's scale and humidity less than 6 percent such as kaolin. limestone, calcite, marble, Talcum, barite, gypsum, dolmite, bentonite mud, mica, pyrophyllite, sepiolite, diatomite, graphite, alunite, fluorite, potassium feldspar, phosphorite, pigment and so on. The granularity of the end products is 325-2500 meshes (0 044-0.005mm).

The main bearing and each dial are driven by electromotor of main equipment through reducer, and numbers of rings and rolls the which are rolling in the ring channels are driven by dial through plunger. After being crushed by hammer crusher, thebig materials Become small ones and they are sent to the storage bin by elevator. The electromagnetic vibrating feeder sends them to the middle of first dial evenly; the materials willbe driven to the edge of dial by centrifugal force, and fall intothe ring channels and are pressed, crushed and ground by the grinding of rings and rolls. Then the materials fall into the second and third ring and crushed and ground. The high pressure centrifugal blower inhales air from the outside and blow the materials roomates are grounded in the third ring to powder Separator. The rotating turbo in the powder separator makes the coarse materials return to the mill and reground, while the fineness mixes with the air and be drawn to the cyclone and be discharged from the discharging valve the which is in the bottom of it. The roomates water mixed with very little fineness are purified by impulse dust catcher and discharged by blower and muffler.

Hig h - efficiency and low consumption With the same end-products fineness and the motor power, its output is over 1 time of that of Jet miii, Mix Mill, and bail Mill.
Easy-damaged parts with longer working life The grinding roll and ring are made of special materials. Generally, Reviews their work life is more than one year, but, whichould come up to over 3 years, when it processes calciumcarbonate and Calcite.
Security and reliablity Because there are no rolling bearings and bolts in the grinding chamber, we can not see the problems of bearings and sealings Easily damaged and machine destroyed due to the bolts looseness.
Cleansing and Environment Protection Adoption of Pulse dust collector and muffler Reduces the industrial dust pollution and noise, the which Reaches the nationalstandard.
